Video Measure & Markup - cross sections, exploded views, visibility
intuitive & practical 3D without CAD expertise
affordable & universal many 3D/2D interfaces
Video Contents
This is the third video tutorial on the measurement functions in the 3D-Tool CAD Viewer. It shows how to measure more complex 3D models and work with many dimensions. Use dynamic cross sections to measure internal geometry. Measure parts in exploded 3D assemblies. Hide or show all annotations and dimensions, or individual ones, in the CAD Viewer. Transfer your measurements and notes to other applications such as spreadsheets or word processors.
